65-98 inch Wall Mount LCD Touch Computer Monitor Infrared Multi
Riotouch FHD LED all in one touch monitor is an interactive TV, it built-in with LED and touch screen (and PC
for optional). We use the most popular technology infrared touch
and the most popular PC -OPS
to meet different demands , make the goods more convient . We also
use the front touch screen frame ,easy for maintain and after-sales
.
Interactive LED touch panel & LED touch sreen monitor with OPS PC
Specifications
- Infrared Touch Technology
- Interactive Whiteboard Solution
- Finger or pen touch and write
- Mul touch (32 point touches )
- Without projector all in one touch monitor
- Win7 32bit and 64bit multi-touch
- Support Microsoft surface
- Sumsung or LG or Sharp LED
- OPS (PC)
Application :
1. Business Institutions: Department Store, Super Market, Exclusive
Store, Hotel, Restaurant, Medicine Store, etc.
2. Financial Institutions: Bank, Stock Market, Insurance Company,
etc.
3. Public Services: Hospital, School, Telecom Hall, Post Office,
etc.
4. Public Places: Subway, Airport, Bookstore, Park, Exhibition
Center, Stadium, Museum, Ticket Agency, HR Market, Lottery Center,
etc.
5. Real Eatates: Apartment, Villa, Business Building, etc.
6. Entertainment Places: Cinema, Gym, Holiday Inn, Nightclub,
Massage Parlor, Internet Cafe, Golf, etc.
Specification:
| LED | LED Panel Size : | 65" |
| Touch screen monitor size (without hot keys): | 65”(without hot keys) |
| LED Brand | CMO/LG |
| Packing Detail | External size(mm): | 1504*928*93.8mm(without wall mount) |
| Customize balckBoard Size(mm): | 1504*928*139.8mm |
| Touch size(mm): | 1431.9*808.3mm |
| Carton size(mm): | 1720*1060*260mm |
| Net weight: | 44kg |
| Gross weight: | 56kg |
| Power Standard | Power : | < 250W |
| standby power: | ≤1Ｗ |
| Display | Display area : | 1428.48 (H) x 803.52 (V)mm |
| Pixel size: | 0.744(h)*0.744(v)mm |
| Display colors : | 16.7M colors |
| Resolution: | 1920x1080pixel |
| Brightness: | 350cd/m2 |
| Viewing angle: | 178 Degree |
| ＴＶ | TV Standard: | ATV(PAL/BG+DK)+DTMB |
| Video Format | MPEG1,MPEG2,MPEG4,H.264,RM,RMVB,avi |
| USB2.0 Multimedia Function | Video/Audio/Photo/txt |
| USB online upgrade | Support USB upgrade online |
| Resolution: | 1920*1080 |
| Android | Main Board | 828 |
| Android Version | Android 5.0 |
| CPU | ARM A53 X4 1.4GHz |
| GPU | Multi-core Mail-450MP2 |
| RAM | 1.5G |
| ROM | 4G |
| Function Description | Support ONE key for Switch and ONE key for Power saving; Support
writing function whitout PC;；Support Touch Menue ,can swith any
access on surface
Support any Channel Screen Cut ,
Support Android whiteboard function ,can fluency writing ,
Annotations, cleaning color
Support Browsing;
Support HD video play, support 1080P;
support local and online Music Playing;
Support Browing Multi format images;
Support Office and other docment Browing and managment;
Support USB update software;
Support wifi wireless |
| Input and Output | HDMI Version : | HDMI 2.0 HDCP 1.4 |
| Scan Method | Support 1080i 1080Pinterlace progressive scan |
| Audio Output | 2X10W |
| Touch | 2 Lines USB2.0 (Front one Line Rear One line ,Can not use same time
) |
| SD Card | 1 line ( Max Support 64G) |
| TV Board USB Input : | 2 Lines (USB 3.0) |
| HDMI Input : | 4 Lines(Outside *2,Build in *1,Build in OPS(4K*2K)*1) |
| VGA Input : | 1 Line |
| PC Audio Input : | 1 Line |
| YPBPR Input: | 1Line |
| AV Input: | 1Line |
| AV Output : | 1line |
| RJ45 Input : | 1 Line |
| Earphone Output: | 1Line |
| Coaxial OutPut | 1 line |
| RS232 Input | 1Line |
| TOUCH-B Input : | 1Line |
| RF Input : | 1 Line (Optional ) |
| HDMI Output | 1 Line |
1. Support 32 touch points ,it means 2-10 people can write at the
same time .
2. Front touch screen frame , the touch part is paste on the TV
,good for maintain and after sales .
3.Use the most popular PC -OPS , OPS is a mini PC ,easy to maintain
.
4.FHD and HD LED touch screen monitor too choose
For school, kidergarden ect.
Package : 1 Set / carton ( carton Inside +wooden carton outside )
Delivery time :3-20 working days after the payment is checked
MOQ:1 Sets
Accept OEM sevice
Size : 42'', 47'',55'',65'',70'',84'' and customized size .
More information ,please viste our website : www.riotouch.com
Contace me : Miss Yevazhang
Whatsapp: +8613632488741
1. What is the infrared technology ?
Infrared technology is most popular now ,it's stable than other
technology ,like CCD ,EM board
2. How many touch does the infrared technology support ?
Infrared technology support 32 touch points now , it's more than
CCD ( the best is 4 touches and EM board is 2 touches )
3. Why I didn't sound you brand " RIOTOUCH '' before ?
We often OEM for good brand , If you want to OEM ,we also can
support .
4. If you can support the teaching software ?
Yes ,We can support the teaching software freely or OEM software .
It's including math ,English ,Physic ,Chemistry subject resource . Over 28 language and
also support you local language .
